Panel saw is any type of sawing machine that cuts sheets into sized parts. Panel saws are used by cabinet shops to easily cut plywood andmelamine sheets into cabinet components. They are also used by sign shops to cut sheets of aluminum, plastic and wood for their sign blanks. Panel saws typically fall into one of two categories: Horizontal and Vertical. Some higher end panel saws feature computer controls that move the blade and fence systems to preset values. Other lower end machines offer simplicity and ease of use.
Detail machine pictures, all photoes are for 100% real shooting ! For more pictures, video and details, please email me!
1 Product Details Show
![Plywood Sheet Cutting Machines, Plywood Sheet Cutting Machines, Cutting Machines of Mds and Plywood Sheet Computers](https://img3.grofrom.com/boyu/b229955171cb6a2967a724122e135e63.webp)
3,All the models
4, Features
1. this machine is suitable for processing all kinds of MDF, Particleboard, ABS sheet, PVC sheet, plexiglass panels and solid wood structure and hardness similar to that of the plate.
2 ,Maximum sawing thickness is 120mm;.
2, G model with industrial control computer as the control center, with the optimization software, production and operation is simple;
3, P330HG can be designed with a single software and seamless docking, to achieve intelligent production of furniture;
4, P330HG configuration of the South Hing optimization software, help to improve the utilization of plate;
5, double independent side shoot technology to ensure the accuracy of sawing;
6, the former air floating beads work table, so that the delivery of the plate is more light and smooth operation, reduce the damage to the plate,
7. Suitable for batch production.
8. Mobile Workbench straight steel rails, wear-resistant, precisely and flexibly.
9. Mobile Workbench uses the high strength extruded aluminum alloy, high strength, and not changed.
10. Mobile table surface oxidation, beautiful and durable.
11, and secant of main saw blade saw blade angle displayed by the intuitive precise angle.
12, main blade lifting screw nut structure, stable and reliable.
13. Secant line saw blade lifting, swinging by the handle adjustment, simple and efficient. Using high quality precision cylindrical Guide, activity light, high accuracy and long service life. Main saw blade lifting Assembly adopt imported precision linear Guide and is equipped with automatic timed greasing system, which effectively guarantees the precision of linear guides, easy to use. Superior cutting ability, Super saw momentum. 50% higher than other similar devices, and make cutting smoother. Main saw blade slot sawing with electric lift, simple and convenient operation.
Our band saw machine is the band type to saw wood at straight line. Applied for processing square wood that have sawed by large saw machine. Also can process small size of wood material, constructive batten or package board. It is good to use in furniture factory, constructive industry and forestry processing etc.
The machine is mainly used for sawing of wood, plastic, and other soft materials. It's fit to the production of square and curve wood with a tilting saw.
![Plywood Sheet Cutting Machines, Plywood Sheet Cutting Machines, Cutting Machines of Mds and Plywood Sheet Computers](https://img3.grofrom.com/boyu/66c4386d6d390d789377bc4294290a72.webp)
![Plywood Sheet Cutting Machines, Plywood Sheet Cutting Machines, Cutting Machines of Mds and Plywood Sheet Computers](https://img3.grofrom.com/boyu/0ddd11f652badd68095207ef7363844b.webp)
![Plywood Sheet Cutting Machines, Plywood Sheet Cutting Machines, Cutting Machines of Mds and Plywood Sheet Computers](https://img3.grofrom.com/boyu/8cdb04219546d67ef0294d502276b1a5.webp)
8, Company Information
Qingdao Xinlihui Machinery Co., Ltd is one of the large-scale woodworking machinery manufacturer in China. The company is located in Wangtai town.
Our company is a comprehensive enterprise which is specialized in research and development, design, manufacturing, sale and service. With advanced production equipment and professional technical staff of research and development, and management. Which is formed a unique management model and the standardization of production process.
The leading products of woodworking products are CNC router, panel saw series, sanding machine series, woodworking drill machine, Pur wrapping machine, paper sticking machine, vacuum laminating machine, edge banding machine, computer engraving machine and the other series and over sixty standards. With the scientific management, unique technology, and innovative products to meet customer demands. Our products get a very high reputation from our customers at home and abroad. Our products are sold across the country and to Russia, Ukraine, Middle-East, South Africa, Southeast Asia, Central Europe and the other countries and areas. We have earned the trust of customers and our product process is in the leading level among the same industry of domestic. It creates a famous brand called "XINLIHUI" and our products sell well both at home and abroad. It is the most trusted brand to our customers.
We would like to work a new win-win development with the insight colleagues and we welcome all the new and old friends to visit our company and crest a brilliant tomorrow together.
![Plywood Sheet Cutting Machines, Plywood Sheet Cutting Machines, Cutting Machines of Mds and Plywood Sheet Computers](https://img3.grofrom.com/boyu/e2f166b9ca2d59f0408fddf293c2f8cb.webp)
![Plywood Sheet Cutting Machines, Plywood Sheet Cutting Machines, Cutting Machines of Mds and Plywood Sheet Computers](https://img3.grofrom.com/boyu/fd89dbf91040c591d43a02fae57eff64.webp)
Detail machine pictures, all photoes are for 100% real shooting ! For more pictures, video and details, please email me!
1 Product Details Show
![Plywood Sheet Cutting Machines, Plywood Sheet Cutting Machines, Cutting Machines of Mds and Plywood Sheet Computers](https://img3.grofrom.com/boyu/b229955171cb6a2967a724122e135e63.webp)
2,Technical parameters
Model | P330H |
Max.cutting length | 3280mm |
Max.cutting thickness | 120mm |
Diameter of main saw blade | Φ460mm |
Diameter of scoring saw spindle | Φ180mm |
Main saw rotating speed | 4200rpm |
Scoring saw rotating speed | 6500rpm |
Saw carriage forward speed | 5-80m/min |
Saw carriage backward speed | 100m/min |
Main saw motor | 18kw |
Automatic feeding speed | 80m/min |
Overall dimension(L*W*H) | 5830*6630*1810mm |
Total power | 20.5 KW |
3,All the models
Model | NPL330HG | P330HG | P330H | P330FG (MJK1333FG) | P280FG | P330F (MJK1333F) | P280F |
Max.cutting length | 3300mm | 3300mm | 3300mm | 3280mm | 2830mm | 3280mm | 2830mm |
Max.cutting thickness | 120mm | 120mm | 120mm | 90mm | 76mm | 90mm | 76mm |
Diameter of main saw blade | Φ460mm | Φ460mm | Φ460mm | Φ400mm | Φ350mm | Φ400mm | Φ350mm |
Diameter of scoring saw spindle | Φ180mm | Φ180mm | Φ180mm | Φ180mm | Φ180mm | Φ180mm | Φ180mm |
Main saw rotating speed | 3910rpm | 3910rpm | 3910rpm | 4200rpm | 4200rpm | 4200rpm | 4200rpm |
Scoring saw rotating speed | 4150rpm | 4150rpm | 4150rpm | 6500rpm | 6500rpm | 6500rpm | 6500rpm |
Saw carriage forward speed | 5-80m/min | 5-80m/min | 5-80m/min | 9-50m/min | 9-50m/min | 9-50m/min | 9-50m/min |
Saw carriage backward speed | 100m/min | 100m/min | 100m/min | 100m/min | 100m/min | 100m/min | 100m/min |
Main saw motor | 18kw | 18kw | 18kw | 15kw | 11kw | 15kw | 11kw |
Automatic feeding speed | 80m/min | 80m/min | 80m/min | 50m/min | 50m/min | 50m/min | 50m/min |
Rear feeding speed | 36m/min | - | - | - | - | - | - |
Overall dimension(L*W*H) | 6550×9200×2020mm | 6460×9200×2020mm | 6460×6900×2020mm | 5830*6630*1810mm | 5330*6630*1810mm | 5830*6630*1810mm | 5330*6630*1810mm |
Total power | 35.5 KW | 27.6KW | 27.6KW | 20.5KW | 16.2KW | 20.2KW | 15.7KW |
4, Features
1. this machine is suitable for processing all kinds of MDF, Particleboard, ABS sheet, PVC sheet, plexiglass panels and solid wood structure and hardness similar to that of the plate.
2 ,Maximum sawing thickness is 120mm;.
2, G model with industrial control computer as the control center, with the optimization software, production and operation is simple;
3, P330HG can be designed with a single software and seamless docking, to achieve intelligent production of furniture;
4, P330HG configuration of the South Hing optimization software, help to improve the utilization of plate;
5, double independent side shoot technology to ensure the accuracy of sawing;
6, the former air floating beads work table, so that the delivery of the plate is more light and smooth operation, reduce the damage to the plate,
7. Suitable for batch production.
8. Mobile Workbench straight steel rails, wear-resistant, precisely and flexibly.
9. Mobile Workbench uses the high strength extruded aluminum alloy, high strength, and not changed.
10. Mobile table surface oxidation, beautiful and durable.
11, and secant of main saw blade saw blade angle displayed by the intuitive precise angle.
12, main blade lifting screw nut structure, stable and reliable.
13. Secant line saw blade lifting, swinging by the handle adjustment, simple and efficient. Using high quality precision cylindrical Guide, activity light, high accuracy and long service life. Main saw blade lifting Assembly adopt imported precision linear Guide and is equipped with automatic timed greasing system, which effectively guarantees the precision of linear guides, easy to use. Superior cutting ability, Super saw momentum. 50% higher than other similar devices, and make cutting smoother. Main saw blade slot sawing with electric lift, simple and convenient operation.
Our band saw machine is the band type to saw wood at straight line. Applied for processing square wood that have sawed by large saw machine. Also can process small size of wood material, constructive batten or package board. It is good to use in furniture factory, constructive industry and forestry processing etc.
The machine is mainly used for sawing of wood, plastic, and other soft materials. It's fit to the production of square and curve wood with a tilting saw.
![Plywood Sheet Cutting Machines, Plywood Sheet Cutting Machines, Cutting Machines of Mds and Plywood Sheet Computers](https://img3.grofrom.com/boyu/66c4386d6d390d789377bc4294290a72.webp)
![Plywood Sheet Cutting Machines, Plywood Sheet Cutting Machines, Cutting Machines of Mds and Plywood Sheet Computers](https://img3.grofrom.com/boyu/0ddd11f652badd68095207ef7363844b.webp)
![Plywood Sheet Cutting Machines, Plywood Sheet Cutting Machines, Cutting Machines of Mds and Plywood Sheet Computers](https://img3.grofrom.com/boyu/8cdb04219546d67ef0294d502276b1a5.webp)
8, Company Information
Qingdao Xinlihui Machinery Co., Ltd is one of the large-scale woodworking machinery manufacturer in China. The company is located in Wangtai town.
Our company is a comprehensive enterprise which is specialized in research and development, design, manufacturing, sale and service. With advanced production equipment and professional technical staff of research and development, and management. Which is formed a unique management model and the standardization of production process.
The leading products of woodworking products are CNC router, panel saw series, sanding machine series, woodworking drill machine, Pur wrapping machine, paper sticking machine, vacuum laminating machine, edge banding machine, computer engraving machine and the other series and over sixty standards. With the scientific management, unique technology, and innovative products to meet customer demands. Our products get a very high reputation from our customers at home and abroad. Our products are sold across the country and to Russia, Ukraine, Middle-East, South Africa, Southeast Asia, Central Europe and the other countries and areas. We have earned the trust of customers and our product process is in the leading level among the same industry of domestic. It creates a famous brand called "XINLIHUI" and our products sell well both at home and abroad. It is the most trusted brand to our customers.
We would like to work a new win-win development with the insight colleagues and we welcome all the new and old friends to visit our company and crest a brilliant tomorrow together.
