Hard and Soft PVC sheet/board/panel manufacturing/extruding/making line
Quick Detail:PVC Sheet Production line
1. High quality& best price
2. Sheet thickness: 0.2mm-20mm
3. Sheet width: 600-1200mm
4. CE approved
Description:
1/The main machine adopts imported AC frequency converter driving. The temperature control meters adopt Japan RKC product. The ancillary machine vacuum pump and drawing motor adopt high-quality products.
2/The maintenance is simple. After the screw stem cylinder and mould are exchanged, it can straight extrude imitating wood foamed special material. The result is better than the single screw stem extruder.
3/The sheet extruding production line adopts special-designed screw stem, material cylinder, moulds and processing technology. It is equipped with YF model shaped material ancillary to produce PVC products
Applications:
Application: PVC rigid sheet is widely used as the packaging material in hardware & tools, electron, food, medicine and handcrafts articles, and various kinds of slap-up pressing.
Application: PVC soft board is widely used as the plastic carpet for cars, corridor curtains, table plate, equipment, cases, hardware pad, internal and external decorations.
PVC Rigid Board, PVC Corrugated Board, PVC Wall Build-up Board Production Line
Application: Chemical, electroplating, smelting, water treatment, construction, and water-proof materials.
Application: Decoration in internal wall, kitchen, bathroom of the hotels, bars, office building, villas; also it can be used to the external decoration of buildings; ceiling, table board, flooring, etc.
Specifications:
Model | FPVC-600 | FPVC-1220 | FPVC-1500 |
Products width (mm) | 600 | 1220 | 1500 |
Products thickness (mm) | 2-15 | 2-20 | 3-19 |
Extruder specification | FSJ-65/132 | FSJ-80/156 | FSJ-92/188 |
Capacity ( Max ) | 220kg/h | 400kg/h | 500kg/h |
Main Motor Power | 55KW | 75KW | 110KW |
![Hard and Soft PVC Sheet/Board/Panel Manufacturing/Extruding/Making Line](https://img3.grofrom.com/boyu/969c74d75d0b9de95697eb6398fa3431.webp)
Competitive Advantage:
---The specially designed screws ensure high plastification rate.
---Special T-type die ensure the precise control of thickness of the plastic sheet/board. Temperature controlling system (±1 °C) can precisely control the plastificating process and ensure precise thickness and flatness of the products.
---The thickness of sheet is precisely adjusted by adjusting the screws and oil pressure wheels.
---The calender can freely rise and fall. Unattached roll temperature controlling system can precisely control the temperature of the roll.
---The cutting machine can precisely control the cutting length.
---The winder can automatically adjust the speed and tension and set the width of needed products freely.
---The machine equipped with meter counter can set the length of product.
Tag:
PVC sheet production line, PVC sheet machine, PVC sheet extrusion line, PVC sheet equipment, PVC board machine, PVC board production line
