GROUND PROTECTION MATS connecting Light portable ground mats for heavy equipment ground protection mat
Introduction
Xinxing ground protection mats are perfect for allowing access to construction sites, creating walkways for pedestrians, cars, vans, JCB, cranes over both natural and synthetic turf. Also they are ideal for ground protection over bog or wet areas or uneven surfaces. A superior alternative to plywood and steel, XINXING Light duty ground mats will not warp, rot, crack, delaminate or absorb harmful chemicals. Made of a special HDPE and UHMWPE. Can be used for temporary flooring in various situations.
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/0c6d2c78fdacd0983f18bf60ff820645.webp)
Keywords
Construction road mat, mobile road mat, temporary access road mat, lightweight ground mat, track mat, bog mat, heavy duty flexible plastic temporary road mat, Alturnamats, HDPE ground access mat, UHMW mats, polyethylene ground mats, path mat, mobile ground mat, polymer composite ground mat, road rugs, turf protection ground mats, grass protection ground mat, landscaping mats, heavy duty ground mats, standard duty ground mats, light duty ground mats, amphi mats, duramats, base mats, quick mat. Polymer Road Plates, Composite Road Plate, Double-sided Road Mat, Mobile road pavements, Mobile Road Plate, ground protection mats 4 x 8 ft black, HDPE ground protection mat, plastic ground protection mat
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/2e2a4ba77eb544b898951c456fefd665.webp)
Advantages
APPLICATIONS![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/f0e14e456ccfd04c0c3d67aad06fe565.webp)
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/ce09a0d1f1467378bded72802a0ffda0.webp)
Engineering data of the ground mats
Surfaces types
walkway
mostly used by pedestrians temporary park routes over turf and uneven ground or dusty roads.
flat/panel
this one is plain with no grids, smooth but not slippery
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/2d1b78e8faefbbc413c45c094c9caf2e.webp)
NB; OUR MATS CAN BE MADE TO CUSTOMER SPECIFICATIONS
Properties of XINXING PE mats:
The above date sheet results are based on the present knowledge and our present products and are given without guarantee. Different condition may have a little difference on the properties.
COLORS SPECIFICATIONS
Blue, green, Yellow, White, Red, black
HOW TO INSTALL
1.Lay the ground mats flat on the ground
And insert one edge of the connector in the ground mats holes.
2.Let the second ground mats stand up and let the other end of connector go through the holes of the other ground mats.
3.Then put the second mat down
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/c6ee7961810a2a91e02c15eebaba2ff9.webp)
QUICK MAT
Suitable for more general purpose situations, such as light vehicle, pedestrian walkways, marquee flooring, and general protection on grass, synthetic turf and muddy areas.
Material: virgin HDPE
Recommended thickness: 10mm, 12.7mm, 15mm, 18mm,20mm, 25mm
Color: white, black, green, blue, yellow etc.
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/c0f82127797c6093ce857148f85e1f47.webp)
Whatever kind of mats you require to complete your project, you can find it with us. Contact us today for a free quote by phone
Introduction
Xinxing ground protection mats are perfect for allowing access to construction sites, creating walkways for pedestrians, cars, vans, JCB, cranes over both natural and synthetic turf. Also they are ideal for ground protection over bog or wet areas or uneven surfaces. A superior alternative to plywood and steel, XINXING Light duty ground mats will not warp, rot, crack, delaminate or absorb harmful chemicals. Made of a special HDPE and UHMWPE. Can be used for temporary flooring in various situations.
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/0c6d2c78fdacd0983f18bf60ff820645.webp)
Keywords
Construction road mat, mobile road mat, temporary access road mat, lightweight ground mat, track mat, bog mat, heavy duty flexible plastic temporary road mat, Alturnamats, HDPE ground access mat, UHMW mats, polyethylene ground mats, path mat, mobile ground mat, polymer composite ground mat, road rugs, turf protection ground mats, grass protection ground mat, landscaping mats, heavy duty ground mats, standard duty ground mats, light duty ground mats, amphi mats, duramats, base mats, quick mat. Polymer Road Plates, Composite Road Plate, Double-sided Road Mat, Mobile road pavements, Mobile Road Plate, ground protection mats 4 x 8 ft black, HDPE ground protection mat, plastic ground protection mat
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/2e2a4ba77eb544b898951c456fefd665.webp)
Advantages
- Xinxing ground mats are durable, light weight, and strong. The mats are engineered to provide ground protection and access over soft surface and will provide a firm support base and traction for various activities.
- These ground protection mats save heavy vehicles from getting stuck in mud, bog and marsh condition.
- Creates an instant roadway over virtually any type of terrain (muddy, bog, marshy, uneven or soft terrain).
- Superior alternative to plywood and fiberglass -will not warp, rot, crack or wear out.
- Save times & labor getting vehicles and equipment traversed over difficult terrain.
- Avoid potential injuries to workers incurred while dislodging vehicles & equipment from excessive wear and damage due to operating on unstable ground conditions.
- Easily handled and laid by two men-no need for expensive crane wagons
- Convenient to use unlike steel and plywood which requires more manpower, rots, rusts.
- Highest abrasion resistance of any polymer, 6 times more wear resistant than steel
- Anti-Weather & Anti-Aging
- Self-lubricating, Very low coefficient of friction
- Excellent chemical & corrosion resistant
- superior impact resistant, Noise- absorption, Vibration-absorption
- Temperature range: -2600C ~ +800C; Very high resistance to cold, doesn't become fragile even under -1800C
- High tensile Strength
- Non-Toxic and smell
- UV resistance
- Flame Retardant; Relatively low in water absorption
- Excellent electrical properties
- Good performance in resisting environment stress crack, 200 times of ordinary PE
No adhesion
Light weight and easier to handle and fix
Cost efficient; Resulting in low energy consumption - .Does not rot, split or crack; 100% recyclable
Great liner material for industrial material handling applications
Easy Reprocessed
APPLICATIONS
- Turf protection
- Car park
- Pathways at parks or events
- Construction sites
- Pipeline
- Temporary road
- Emergency access routes
- Civil engineering
- Beach mats
- Airports
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/f0e14e456ccfd04c0c3d67aad06fe565.webp)
- Military mats
- Marine work areas
- Temporary wheelchair pathways
- National Parks
- Landscaping
- Utilities and infrastructure maintenance
- Boat regattas
- Cemeteries
- Caravan parks
- Heritages sites and eco friendly areas
- Golf course and sports field maintenance
- Protection your turf and provide access nearly anywhere
- Temporary flooring
- Stadium ground covering
- Contractors
- Outdoor Events/ shows/ festivals
- Building site access routes
- Construction, civil engineering and ground work industries
- Emergency access routes
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/ce09a0d1f1467378bded72802a0ffda0.webp)
Engineering data of the ground mats
Unit | HDPE | |
Mechanical Properties | ||
Tensile strength | MPa | 23-26 |
Flexural strength | MPa | 25-28 |
Flexural modulus | MPa | 1936-1967 |
Charpy Notched Impact Strength | KJ/m² | 5-6 |
Poisson's ratio | (theoretical) | 0.35-0.38 |
Compression testing(max value before test terminated) | Tons | 250 |
General Properties | ||
Density | KG/m³ | 940-965 |
Shrinkage | % | 2-4 |
Water absorption | % | 0.01 |
Thermal expansion | e-6/K | 110-130 |
Thermal conductivity | W/mk | 0.46-0.52 |
Specific heat | J/kg.k | 1800-2700 |
Melting temperature | ºC | 108-134 |
Glass temperature | ºC | -110- +110 |
Service temperature | ºC | -30- +85 |
Resistivity | ohm.mm²/m | 5e+17-1e+21 |
Break down potential | kV/mm | 17.7-19.7 |
Dielectric loss factory | 0.0005-0.0008 | |
Friction coefficient | 0.25-0.30 | |
Refraction index | 1.52-1.53 |
track way
mostly used by trucks, cranes and cars and other heavy automobiles.walkway
mostly used by pedestrians temporary park routes over turf and uneven ground or dusty roads.
flat/panel
this one is plain with no grids, smooth but not slippery
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/2d1b78e8faefbbc413c45c094c9caf2e.webp)
NB; OUR MATS CAN BE MADE TO CUSTOMER SPECIFICATIONS
Properties of XINXING PE mats:
Factor | Value | ||
HDPE | UHMWPE 100% RE | UHMWPE 50% RE | |
Tensile Strength(MPa) | 22 | 25 | 28 |
Notched Impacted Strength Kj/m2 | No break | No break | No break |
Elongation at break (%) | >100% | >50% | >50% |
Acids-concentrated | Good--Fair | Good-Fair | Good-Fair |
Acids-dilute | Good | Good | Good |
Aromatic hydrocarbons | Fair | Fair | Fair |
Greases and Oils | Good-Fair | Good-Fair | Good-Fair |
Halogenated Hydrocarbons | Fair-Poor | Fair-Poor | Fair-Poor |
Halogens | Fair-Poor | Fair-Poor | Fair-Poor |
Ketones | Good-Fair | Good-Fair | Good-Fair |
Alcohols | Good | Good | Good |
Alkalis | Good | Good | Good |
Density(g/cm ) | 0.93-0.97 | 0.95-0.98 | 0.93-0.96 |
Water absorption-over 24 hours (%) | <0.01 | <0.01 | <0.01 |
Resistance to Ultra-violet | Fair | Fair | Fair |
Radiation resistance | Fair | Fair | Fair |
Dielectric constant@1MHz | 2.3-2.4 | 2.3 | 2.3 |
Dielectric strength(KV/ mm) | 22 | 28 | 28 |
Dissipation Factor@1MHz | 1-10*10 | 1-10*10 | 1-10*10 |
Surface resistivity(Ohm/sq) | 10 | 10 | 10 |
Volume resistivity(Ohm-cm) | 10 -10 | 10 | 10 |
The above date sheet results are based on the present knowledge and our present products and are given without guarantee. Different condition may have a little difference on the properties.
COLORS SPECIFICATIONS
Blue, green, Yellow, White, Red, black
HOW TO INSTALL
1.Lay the ground mats flat on the ground
And insert one edge of the connector in the ground mats holes.
2.Let the second ground mats stand up and let the other end of connector go through the holes of the other ground mats.
3.Then put the second mat down
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/c6ee7961810a2a91e02c15eebaba2ff9.webp)
QUICK MAT
Suitable for more general purpose situations, such as light vehicle, pedestrian walkways, marquee flooring, and general protection on grass, synthetic turf and muddy areas.
Size(mm) | Thickness with texture(mm) | weight (kg) | Effective Surface Area(sqm) | Load Capacity (ton) | Loading container |
2400*1200*12.7 | 22.7 | 40 | 2.88 | 40 | 320pcs in 20'GP 580pcs IN 40 'GP |
2440*1220*12.7 | 22.7 | 42 | 2.98 | 40 | 300pcs in 20 'GP 550PCS in 40'GP |
2000*1000*10 | 20 | 22.6 | 2.00 | 30 | 590pcs in 20'GP 1150pcs in 40'GP |
2900*1100*12.7 | 22.7 | 45 | 3.20 | 40 | 350pcs in 20'GP 580pcs in 40'GP |
3000*1500*15 | 25 | 74 | 4.50 | 80 | 320pcs in 40'GP |
Recommended thickness: 10mm, 12.7mm, 15mm, 18mm,20mm, 25mm
Color: white, black, green, blue, yellow etc.
![Ground Access Mats, Industrial Heavy Duty Ground Protection Mats](https://img3.grofrom.com/boyu/c0f82127797c6093ce857148f85e1f47.webp)
Whatever kind of mats you require to complete your project, you can find it with us. Contact us today for a free quote by phone
