UHMWPE or HDPE FQ 1000 Sliding Fender pads for Marine fender
UHMWPE FENDER PADS Characters :
Item | Test Method | Unit | UHMWPE 1000-V | UHMWPE 1000-DS |
Density | ISO1183-1 | g/cm3 | 0.93-0.95 | 0.95-0.96 |
Yield Strength | ASTM D-638 | N/mm2 | 15-22 | 15-22 |
Breaking Elongation | ISO527 | % | >200% | >100% |
Impact Strength | ISO179 | Kj/m2 | 130-170 | 90-130 |
Abrasion | ISO15527 | Steel=100 | 80-110 | 110-130 |
Shore Hardness | ISO 868 | Shore D | 63-70 | 63-75 |
Friction Coefficient(static state) | ASTM D-1894 | Unitless | <0.2 | <0.2 |
Operating Temperature | - | ºC | -80 to +80 | -80 to +80 |
XINXING UHMWPE1000 ultra high molecular weight polyethylene (UHMW-PE) is the first choice material for facing steel fender panels and other heavy duty applications. They also used in corner pad for marine fender cover/ coner marine fender pads for jetty . It combines very low friction with excellent impact strength and a wear resistance much better than steel. Most popular is XINXING UHWMPE1000-DS which is 'double-sintered' and work-hardened for extra durability. The standard colour is black, but if other colours are needed then UHMWPE 1000-V 'virgin' grade also comes in yellow, white, grey, blue, green and red. UHMW-PE1000 materials are compounded to resist ozone and UV radiation. They do not degrade or rot .
Green UHMWPE Pads for Marine fender/UHMWPE Fender pads Characters:
1.very flat on the surface
2.The thickness tolerance is +2 -0,some made according to your requirements.
3.The color is pure and any color can be made by us.
4.We can give you an accurate size of HDPE plate with advanced machine.
5.Different shaped HDPE plate also can be made by us like bending sheet.
6.According to different requirements with different application, special specifications can be customized, like anti-UV, fire-resistant,anti-static and with other characters.
PE 1000 UHMWPE Marine fender pads/board/plate
Green UHMWPE Pads for Marine fender/UHMWPE Fender pads
Application case 1
![Green UHMWPE Pads for Marine Fender/UHMWPE Fender Pads](https://img3.grofrom.com/boyu/5df92afbde0d9694c6351a2f92c27310.webp)
Green UHMWPE Pads for Marine fender/UHMWPE Fender pads
Application case 2
![Green UHMWPE Pads for Marine Fender/UHMWPE Fender Pads](https://img3.grofrom.com/boyu/2d49a646d44f84807f106f5f2d1d3f85.webp)
Green UHMWPE Pads for Marine fender/UHMWPE Fender pads
Application case 3
![Green UHMWPE Pads for Marine Fender/UHMWPE Fender Pads](https://img3.grofrom.com/boyu/bca5afc98f7b57bd999032d1c84f8b84.webp)
Green wear-resisting UHMWPE 1000 Fender facing plate/pad/panel applications:
Bridge buttress protection
* Pontoon pile guide bearings
* Fast-launch lifeboat slipways
* Beltings for smaller workboats
* Fender panel facing pads
*Fender pile rubbing strips
*UE-V fender shields
*Facing strips for jetties and wharves
*Lock entrance and lock wall protection
*Mitres on lock gates
Application case 1
CNC Machine | ![]() |
Packing | ![]() |
FAQ
Q:Are you a trading company or a manufacturer?
A:We are both, we have our own factory, but also a factory-based trading company.
Q:Can we visit your factory ?
A:Warmly welcome,we located 50 kilometers northeast of Dezhou City. It takes only 1.5 hours from our factory to Beijing and 40 min to high speed railway station.The office has convenient transportation and beautiful environment, which is convenient for receiving guests from all directions.
Q:How can we get the offer?
A:To give you a good price,please offer your company information/trade term;product size/color/quantity
Q: How long is your delivery time?
A: Generally it is 7-15 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.
Q: What are your terms of payment term?
A:T/T or L/C at sight. 50% T/T as deposit, balance before shipping.
Q:What are your terms of delivery methods?
A:ocean vessel, train, air plane or truck as arranged under FOB, CNF/CFR, CIF or DDU terms;
Q:What are your packing way?
A:pallet with stretch film, carton with stretch film, tray or others as your request.
About Shandong Ningjin Xinxing Chemical Co.,ltd Blue UHMW Polyethylene 1000 Fender pads for Marine fender
![Green UHMWPE Pads for Marine Fender/UHMWPE Fender Pads](https://img3.grofrom.com/boyu/82cc1834302664f27f1a885b61f9ee43.webp)
XINXING Certificate
![Green UHMWPE Pads for Marine Fender/UHMWPE Fender Pads](https://img3.grofrom.com/boyu/12e7856795d768b00e19ad54205f8da7.webp)
SHANDONG NINGJIN XINXING CHEMICAL CO.,LTD Established in 1989, Xinxing Chemical Co.,LTD is the largest manufacture of engineering plastics in China. XINXING 's main products include UHMWPE Sheets ,UHMWPE Rods ,HDPE Sheets ,HDPE rods as well as custom machined parts such as UHMWPE Marine Fender pads ,ground protection mats ,crane outrigger pads ,ice rink barrier,dasher board ,shooting pads,Suction box cover , uhmwpe chain guides ,dock bumpers, ect. In addition to these engineering plastic components and products ...
